DETAILS
Thanks to its high performance, it cuts low-alloy steels, stainless steels, and aluminum alloys flawlessly.
Features
Thanks to its 3-phase 380V AC input power and maximum 60 A cutting current, it enables cutting low-alloy steels up to 20 mm thick.
Thanks to the inverter technology used in its production, a smooth cutting surface is achieved despite its small size.
Thanks to its new-generation electronic circuit design, it is significantly smaller than older-technology plasma cutting machines and weighs only 13 kg.
Thanks to its "Hall Sensor" technology, the output current remains constant even if the distance of the torch to the workpiece changes due to operator deflection, ensuring perfect cutting at the set current value.
The grid cutting feature allows continuous, non-stop cutting of grids, railings, and similar materials with gaps in between with just a single press of the torch trigger. It is equipped with a thermal warning light that illuminates if the machine overheats or experiences sudden current surges due to mains overloads.
The machine's advanced electronic design and secure grounding connections allow for safe metal cutting without the risk of life-threatening electric shock.
The high-strength rubber-coated power cable ensures safe operation during welding.
Because it is not affected by mains noise or electromagnetic fields emitted by other nearby devices, there is no loss of performance during the cutting process.
The air pressure gauge on the front panel allows for easy control and adjustment of the machine's air pressure.
Specifications
Machine Inputs and Outputs
Phase 1: Input Voltage #1 (Voltage/Phase/Frequency) 380 V; 3~Phase; 50/60 Hz
Phase 1: Rated Output #1A (Current/Voltage/Duty Cycle) 60 A; 104 V (40%)
Phase 1: Rated Output #1B (Current/Voltage/Duty Cycle) 43 A; 97.2 V (100%)
Phase 3: Input Voltage #1 (Voltage/Phase/Frequency) 380/3/50/60
Phase 3: Rated Output #1A (Current/Voltage/Duty Cycle) 60A/104V/40%
Phase 3: Rated Output #1B (Current/Voltage/Duty Cycle) 43A/97.2V/100%
Product Weights and Dimensions
Product Height (mm) 280
Product Width (mm) 165
Product Length (mm) 495
Product Weight (kg) 13
Machines
Machine Communication Technology Analog
Basic Features
Open Circuit Voltage 225 V (DC)
Number of Operators per Machine 1
Input Voltage: 380 V
Input Current: 15.0 A (40%)
Input Frequency: 50/60 Hz
Input Phase: 3
Input Power: 8.0 kW (40%)
Output Range: 20 - 60 A
Plasma Cutting Machines
Plasma Machines Process Cutting
Torch Included: Yes
Torch Cooling: Air
Recommended Cutting Capacity (Non-Alloy Steel) (mm/M) 20
